114779 PUMPS-CENTRIFUGAL
  • ITEM NO :  114779
  • QTY :  1
  • ALLOY :  S
  • GPM :  300
  • FT HEAD :  151
  • PUMP CASE RPM :  3520
  • CASE MATERIAL :  316SS
  • IMPELLER MATERIAL :  316SS
  • V/H :  H
  • MANUFACTURER :  SULZER
  • MODEL :  OHH
  • SIZE :  4X3X8
  • DRIVER TYPE :  MOTOR
  • HP :  25
  • RPM :  3520
  • VOLTAGE :  460
Technical Drawings/Spec Sheets
View Documents Aux Piping
View Documents Coupling
View Documents Mech Seal Data
View Documents Mechanical Seal
View Documents Motor Data
View Documents Motor Nameplate
View Documents Pump cross section
View Documents Pump data sheets
View Documents Pump general arrangement
View Documents Pump Nameplate
View Documents Pump performance data
View Documents Seal support system
ADDITIONAL DESCRIPTION
Unused vertical Centrifugal Pump. T-10003 Recirculating Pump. Mfg. by Sulzer. Size 3x4x8A-1; 300 gpm. 151' head. 574 psi @ 250 deg. F. Casing 316SS; Impeller 316SS. API Class: A-8. With 25 hp motor.
