114656 TANKS
  • ITEM NO :  114656
  • QTY :  1
  • ALLOY :  S
  • GALLONS :  2800
  • DIA/WIDTH (FT'IN") :  7'1"
  • LENGTH (FT'IN") :  8'2"
  • SHELL PSI :  ATMOS
  • FULL VAC. Y/N :  N
  • SHELL TEMP DEG. F :  122
  • V/H :  V
  • SHELL MATERIAL :  304SS
  • CODE :  NO
  • JKT/COIL PSI :  58FV
  • JKT/COIL TEMP DEG. F :  380
  • JKT/COIL MATERIAL :  304SS
  • AGITATED Y/N :  N
  • TOP HEAD :  FLAT
  • BOTTOM HEAD :  CONE
Technical Drawings/Spec Sheets
View Documents Drawing
View Documents Assy Nameplate
View Documents Equipromex Final Inspection Report
ADDITIONAL DESCRIPTION
Unused 2800 gallon vertical 304 stainless steel tank with 304 stainless steel steam coil. Filter elements cleaning tank. Mfg. by Equipromex (Mexico) in 2022. 7'1" diameter x 8'2" T/T. Flat top and cone bottom. On lug supports.
