114639 VESSELS/REACTORS
  • ITEM NO :  114639
  • QTY :  1
  • ALLOY :  S
  • GALLONS :  1100
  • DIA/WIDTH (FT'IN") :  4'0"
  • LENGTH (FT'IN") :  12'0"
  • SHELL PSI :  105
  • FULL VAC. Y/N :  Y
  • SHELL TEMP DEG. F :  500
  • V/H :  V
  • SHELL MATERIAL :  316LSS CLADDING
  • CODE :  ASME
  • WALL :  .375"
  • AGITATED Y/N :  N
  • TOP HEAD :  DISHED
  • BOTTOM HEAD :  DISHED
Technical Drawings/Spec Sheets
View Documents Design Calculation
View Documents Drawings
View Documents GA Drawing
View Documents Nameplate
View Documents Transport Data
View Documents Transport Drawing
YouTube Videos
Unused Vessel Link Vessel
ADDITIONAL DESCRIPTION
Unused 1100 gallon Vertical AGR1 Amine Regenerator Reflux Drum. 4'6" diameter x 12'0" T/T. Material of Construction - Shell: 316L stainless steel cladding. 20"0" skirt support, shell wall thickness .315" carbon steel plus .125" 316L stainless steel cladding. 2:1 elliptical dished heads, .472" thick carbon steel with .125" thick 316L stainless steel cladding.
