114592 TANKS
  • ITEM NO :  114592
  • QTY :  1
  • ALLOY :  S
  • GALLONS :  35000
  • DIA/WIDTH (FT'IN") :  14'0"
  • LENGTH (FT'IN") :  30'0"
  • SHELL PSI :  ATMOS
  • V/H :  V
  • SHELL MATERIAL :  304SS POLISHED
  • WALL :  12 GA.
  • AGITATED Y/N :  N
  • TOP HEAD :  CONE
  • BOTTOM HEAD :  FLAT
Technical Drawings/Spec Sheets
View Documents Drawing
ADDITIONAL DESCRIPTION
Used 35,000 gallon Single wall Storage Tank. Manufactured by ICC Northwest in 2022, 304 stainless steel Polished vertical silo, 14ft Diameter X 30ft High, front manways, Skirt Supported, Flat botton Head, Cone Top Head, Top Head--10 ga(.135"), Shell--12 ga. (.1054"), Bottom--7 ga.(.1854") Atmospheric
