114759 EXCHANGERS
  • ITEM NO :  114759
  • QTY :  1
  • ALLOY :  S
  • SQ.FT. :  353
  • MATERIAL (S) :  CS FRAME
  • MATERIAL (T) :  316LSS PLATES
  • PSI (S) :  87FV
  • PSI (T) :  87FV
  • TEMP. DEG. F (S) :  248
  • TEMP. DEG. F (T) :  248
  • V/H :  V
  • CODE :  NB
Technical Drawings/Spec Sheets
View Documents (no title)
View Documents (no title)
View Documents (no title)
View Documents (no title)
View Documents (no title)
View Documents (no title)
ADDITIONAL DESCRIPTION
Unused 353 sq. ft. vertical Compabloc heat exchanger. 2.3 Design duty (MMBTU/Hr). Mfg. by Alfa Laval Vicarb in 2021. Model #CPX40. Shell: 87FV psi @ 248 deg. F. Tubes: 87FV psi @ 248 deg. F. Oil/Water heat exchanger. Under Nitrogen Purge
