114613 TANKS
  • ITEM NO :  114613
  • QTY :  1
  • ALLOY :  S
  • GALLONS :  2162
  • DIA/WIDTH (FT'IN") :  6'6"
  • LENGTH (FT'IN") :  8'0"
  • SHELL PSI :  ATMOS
  • FULL VAC. Y/N :  N
  • SHELL TEMP DEG. F :  200
  • V/H :  V
  • SHELL MATERIAL :  316LSS POLISHED (NEED TO VERIFY IF 304 OR 316)
  • CODE :  NO
  • AGITATED Y/N :  N
  • TOP HEAD :  FLAT HINGED
  • BOTTOM HEAD :  DISHED
ADDITIONAL DESCRIPTION
Used 316L polished stainless steel single wall mix tank. Mfg. by ICC Northwest in 2021. 2162 Gallon capacity, 78" diameter x 8' high. Atmospheric @ 200 deg. F. On lug supports, dished bottom head and flat hinged top. (4) internal sidewall baffles. Shaft and blades are in the tank.
